Quick Details

  • Products Status: Stock
  • Style: External
  • Type: Wireless
  • Interface Type: USB
  • Transmission Rate: 128Kbps
  • Certification: CE/ROHS
  • Brand Name: wavecom
  • Model Number: wavecom
  • Place of Origin: Guangdong, China (Mainland)
  • Frequency: 850/900/1800/1900Mhz
  • Inside module: Wavecom Q2406B/q24plus/mc55
  • Gprs transmitting speed: 115KBps
  • voltage: 100 to 250V
  • Working temperature: -40°C-+85°C
  • TCP / IP protocol station: built in
  • SMS per hour: 4800pc
  • Function: SMS, MMS, e-mail and data
  • offical configuration: 1 x power cable, 1x USB cable, CD,8 antenna
  • sim card slot: 16

Packaging & Delivery

Packaging Details box packing
Delivery Time 1-3 days



Product Description



2U 16 Port RJ45 modem pool Q24plus quad band bulk sms modem





Gprs modem pool  basic :

Modelgprs modem pool
Sim card slot16
Main functionBulk sms /mms,data transfer
Working Temperature-40°C-+85°C
SMS per hour9600



Specifications





The Sierra Wireless SL808x (SL8080/81/82/83/84/85) is a 74-pin soldered-down module based on the Intel pin-out specification

proposal for the standard JEDEC LGA packaging form factor. It‘s wireless UMTS-based modem provides data connectivity for eBooks,

portable navigation devices, mobile Internet devices, point-of-sale devices, industrial handhelds, and other machine-to-machine and

vertical applications over the following frequency bands:



1.3G Sierra SL808X frequency band:

UMTS (WCDMA)/HSDPA
SL8080/81: 850 MHz, 1900 MHz
SL8082/83: 900 MHz, 2100 MHz
SL8084/85: 850 MHz, 2100 MHz
GSM/GPRS/EDGE: 850 MHz/900 MHz/1800 MHz/900 MHz
GPS (SL8080/82/84)1575.42 MHz



2.Support:

The SL808x modem supports data operation on HSDPA, WCDMA,EDGE, and GPRS networks. The SL8080/82/84 modems also
support voice operation on these networks.



3.The SL808x modems are based on Qualcomm baseband processors:

Voice modems: SL8080/82/84—QSC6270
Data modems: SL8081/83/85—MDM6270



4.Application interface features:
NDIS NIC interface support (Windows XP, Windows Vista, Windows 7,Windows CEa, Linux)
 Multiple non-multiplexed USB channel support
 Dial-up networking
 USB selective suspend to maximize power savings
AT command interface—(non-voice) 27.007 standard, plus proprietary extended AT commands



5. Packet mode feature
Dual-mode UMTS (WCDMA) / HSDPA / EDGE / GPRS operation
• GPRS class B, multislot class 10 operation—Supports CS1–CS4
coding schemes
• EDGE multislot class 12 operation—Supports MCS1–MCS9 coding
schemes
• UMTS (WCDMA) R99 data rates—384 kbps downlink, 384 kbps uplink
• HSDPA
· Category 5/6 data rate—3.6 Mbps (peak rate)
· Category 12 data rate—1.8 Mbps
• Circuit-switched data bearers—64 kbps (maximum) uplink and
downlink



6.Voice mode features (SL8080 / 82 / 84 only)

Supports:

• All GSM vocoders, Enhanced Full Rate (EFR), Full Rate (FR), Half

Rate (HR), and WCDMA Adaptive Multirate (AMR) encoders

• MO and MT calling

• Echo cancellation

• Emergency calls (112, 110, 911, etc.)

• Incoming call notification

• TTY/TDD compatibility through microphone/speaker connections

using the audio interface



7.GPS features (SL8080 / 82 / 84 only)

Provides:

• Standalone GPS functionality

• gpsOneXTRA™

• A-GPS features

• NMEA support



8.SUPPORTED OPERATATING SYSTEMS

♦ Windows 7 (Home, Premium, Pro, Ultimate, Enterprise)

♦ Windows Vista (Home, Business, Ultimate, Enterprise)

♦ Windows XP (Pro and Home)

♦ Windows Server 2003 (original and R2)

♦ Windows 2000



 RJ45 modem pool Parameter:

 Module

Sierra SL8080/81/82/83/84/85

 GSM Band

GSMGPRS/EDGE:8500/900/1800/1900MHZ

3G Band

850/1900MHZ, 900/2100MHZ.850/2100MHZ

Internet

Wireless Access to internet

Design

Industrial Design

Interface

RJ45 interface.

Sim slot

8 SIM card slots(BIG &SMALL)

Transmitting Speed

Maximum Transmitting Speed 3.6Mbps

temperature

Working temperature -20 to +60 degrees

Working temperature -20 to +60 degrees

Support

With TCP/IP stack

Internet Services: PPP,TCP, UDP, HTTP, SMTP, POP3

Open AT/STK

GPS function

voice function

Remote control access

Data Transfer

Send and receive SMS, MMS, e-mail and data,USSD

Operating system

windows,VISTA,LINUX,XP etc

Input Voltage

110V-240V

Size

193*115*130MM

Weight

5.00 Kg

Accessories

1pc power cable, 8pcs antennas,1pc rj45 cable,1pc cd driver

Delivery time

About 2-5 business days after receiving the payment

RJ45 VCOM advanced usage:

VCOM can be used as TCP Server or TCP Client to build communication with com port server. In this way,
It can establish communication between upper pc which on two ends of the WAN and terminal equipment’s comport.

upper PC has fixed Wan IP address

VCOM as TCP Server,com port server as TCP Client .The working mode on com port choose TCP/UDP Socket, set up
detailed protocol TCP Client,the other side host fill upper pc’s IP address, The other side port fill the port which set in VCOM .

RJ45 modem pool driver
COM mapping and TCP/IP adress configuraton







The package includes 1x modem,8 x antenna,1x RJ45/USB cable,1x Power adapter,1x CD



How to insert sim cards ?





Operating System





Power Adapter



Packaging & Shipping



Packing : Neutral packing

Shipping: DHL/EMS/UPS/TNT/FEDEX



Our Services



We offer the best services and saleafter to our customers, Pls feel free to contact us!

Before packing,we have strict testing system to insure the high quality of our goods.
